DS45SIDE FRIDGE DROP SLIDE™

Part Number: DS45SIDE

LIGHTER. STRONGER. SAFER. SMARTER.

MSA 4X4's DS45SIDE Fridge Drop Slide™ is an innovative, patented design which allows you to safely lower your fridge, providing easy, convenient access to its contents.

Designed for applications where your slide is more suitably mounted sideways, the Side Drop Slide™ coasts smoothly out from its stowed position, before lowering 30cm in a safe and easy motion. This allows for the tray to remain in a horizontal position through the entire motion. The DS45SIDE allows for complete access to the front and side of your fridge. It also offers a compact design which will not decrease storage space in your vehicle.

The refined, patented design of our DS45SIDE Drop Slide™ features 800NM quality gas struts, providing safe, easy lifting and lowering for loads up to an incredible 200kg. Now you can fill your fridge and access it with ease!

Features:

Compact size won't decrease storage space in your vehicle.
No drawer disassembly required to install the slide.
Designed to swing smoothly out further past the vehicle tailgate, providing easy and convenient access to the contents of your fridge from its complete front and side.
Unique lock-in lock-out safety feature.
Heavy duty 200kg slide runner rating.
Tie down straps & all fixings included as standard.
Stainless steel & blue anodised handle and face plate.
Fridge Barriers available to suit for extra fridge protection & increased storage possibilities.
Pre-drilled holes in the tray provide convenience in accommodating most popular fridges.

Specifications

Weight:	40 kg
Freight Dimensions:	110 × 69 × 17 cm
Slide Dimensions:	(all measurements displayed are in mm)
Fridge Tray:	730 x 460
Drop:	300
Slide Length Closed:	530 + 20
Slide Length Open:	1170 + 20
Overall Width:	870 + 20
Mount to Base:	35
Load Limit:	200kg
Max Set Back:	125
Gas Strut:	800N
Handle Width:	815
Suits These Fridges:	MYCOOLMAN CCP36 SINGLE ZONE, MYCOOLMAN CCP44 SINGLE ZONE, ARB 35 L, ARB 47L, BUSHMAN 35L, BUSHMAN 42L, BUSHMAN 45L, BUSHMAN 52L, EVAKOOL G45 (GLACIER), EVAKOOL G55 (GLACIER), EVAKOOL SK45, EVAKOOL SK55, EVAKOOL SK65, EVAKOOL TRAVELMATE TMX 55, EVAKOOL TRAVELMATE TMX 65, PRIMUS 31L (INDEL B), PRIMUS 40L (INDEL B), PRIMUS 45L (MAMMOTH), PRIMUS 50L (INDEL B), PRIMUS 60 (MAMMOTH), PRIMUS 60L – RED LID, PRIMUS 60L DUO – RED LID, TECHNIICE 42L, WAECO CFX 35 – NEW/M, WAECO CFX 40 – NEW/M, WAECO CFX 50 – NEW/M, WAECO CFX 65 – NEW/M

Notes

Please Note: We keep many of these in stock, but are unable to keep all.
Generally these are made to order with a 2-3 week lead time currently. If in stock they will dispatch immediately. Please note, these are an order in item - generally 2-3 weeks from order time.
